EXPLORER 2717 TRANSIT CASE

Dimensions:
External Dimensions (L x W x D): 305 x 270 x 194mm
Lid / Base Height: 35 + 135mm

Colour: black, orange

Options: no foam, with pluck-able foam, full customisation service available

2717 Explorer Case Features:

  • PVC Waterproof I.D Removable Label
  • Sealing O-Ring
  • Corrosion proof Metal Hinges With Lid Stay Features
  • Internal Slots – internal slots for optional panel mounting brackets or panel mounting rings
  • Latch
  • Manual Pressure Release Valve – internal stop ring prevents valve from being completely extracted
  • Counterbalance Supports
  • Lid can be set to slide off – by releasing the back screw, lid becomes set to slide off when opened at 70 degrees
SKU: EX2717 Categories: , ,

Description

Internal Dimensions:
Length – 276mm
Width – 200mm
Depth – 170mm
Lid – 35 mm
Base – 135mm

External Dimensions:
Length – 305mm
Width – 270mm
Depth – 194mm

Weight Empty (No Foam): 1,93 Kg
Weight Full (With Foam): 2,12 Kg

Volume: 7Lt

Buoyancy: 4,20kg/max

Certification:
2002/95/EC Conformity with the Directive 2002/95/EC
DEF STAN 81-41 (level J)
IP67 Dustproof – Waterproof
STANAG 4280 (edition 2)
